◎Cold and hot water pipes in residential buildings◎Pure water conveying pipe◎Hot water circulation and heating supply pipe◎Tap water pipe◎Aquaculture pipe◎Water treatment pipe◎Food, beverage, drug factory water conveying pipe◎Industrial cold and hot water conveying pipes◎Central air conditioner condensate water conveying pipe◎Compressed air pipe
Return| specifications | D | D1 | d | I | L | H | G | A/box |
|---|---|---|---|---|---|---|---|---|
| Φ20x(1/2)" | 27.5 | 35.5 | 19 | 16.5 | 44.5 | 48.5 | 1/2" | 50×8 |
| Φ25x(1/2)"3 | 34.5 | 36.5 | 24 | 18.5 | 47 | 54 | 1/2" | 40×8 |
| Φ25x(3/4)" | 34.5 | 44.5 | 24 | 18.5 | 52.5 | 55.3 | 3/4" | 30×8 |
| Φ32x(1/2)" | 43.5 | 40.5 | 31 | 21 | 58 | 66 | 1/2" | 20×8 |
| Φ32x(3/4)" | 43.5 | 45.5 | 31 | 21 | 54.5 | 62.5 | 3/4" | 160 |
| Φ32x1" | 43.5 | 59 | 31 | 64.5 | 65 | 1" | 10×8 |
